Binary Pressure Switch, Normally Open
Binary Pressure Switch, Normally Open
Regular price
$47.00
Regular price
Sale price
$47.00
Unit price
per
Couldn't load pickup availability
OEM part numbers
AL112954, AL168231
AL112954, AL168231
Item Information
High Low Protection High Side
Binary Type Switch
Binary Type Switch
Specifications
| TYPE | Normally Open |
| LOW PRESSURE - OPENS | 28 PSI Falling Pressure |
| LOW PRESSURE - CLOSES | 25 PSI Rising Pressure |
| HIGH PRESSURE - OPENS | 350 PSI Rising Pressure |
| HIGH PRESSURE - CLOSES | 220 PSI Falling Pressure |
| THREAD SIZE | 7/16" X 20 |
Compatible With
John Deere Tractors5065M, 5070M, 5075M, 5080M, 5080RN, 5083E, 5085M, 5090M, 5090RN, 5093E, 5095MH, 5101E, 5105M, 5125R, 5225, 5325, 5425, 5525, 5603, 5625, 6100D, 6100MC, 6110, 6110D, 6110MC, 6110RC, 6115D, 6125D, 6130, 6130D, 6140D, 6140J, 6145J, 6155J, 6165J, 6180J, 6200, 6200L, 6215, 6220, 6230, 6300, 6300L, 6310, 6310S, 6320, 6330, 6400, 6400L, 6403, 6405, 6410, 6410S, 6415, 6430, 6500, 6500L, 6510, 6510S, 6530, 6603, 6605, 6615, 6630, 6715, 6800, 6830, 6900, 6930, 7130, 7220, 7230, 7320, 7330, 7420, 7430, 7505, 7515, 7520 MFWD, 7530, SE6920
John Deere Tractors5065M, 5070M, 5075M, 5080M, 5080RN, 5083E, 5085M, 5090M, 5090RN, 5093E, 5095MH, 5101E, 5105M, 5125R, 5225, 5325, 5425, 5525, 5603, 5625, 6100D, 6100MC, 6110, 6110D, 6110MC, 6110RC, 6115D, 6125D, 6130, 6130D, 6140D, 6140J, 6145J, 6155J, 6165J, 6180J, 6200, 6200L, 6215, 6220, 6230, 6300, 6300L, 6310, 6310S, 6320, 6330, 6400, 6400L, 6403, 6405, 6410, 6410S, 6415, 6430, 6500, 6500L, 6510, 6510S, 6530, 6603, 6605, 6615, 6630, 6715, 6800, 6830, 6900, 6930, 7130, 7220, 7230, 7320, 7330, 7420, 7430, 7505, 7515, 7520 MFWD, 7530, SE6920
